IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light

Minimum Order Quantity : Negotiation Price : Negotiation
Packaging Details : sea worthy : professional packing, plastic bag, carton, pallets if clients needed. Delivery Time : Depends on the quality of client
Payment Terms : 30% advanced payment , 70% balance payment before shipment. Supply Ability : 50000 Piece/Pieces per Month
Place of Origin: China Brand Name: DINGLI
Certification: CE, ETL, RoHS Model Number: HID, HPS/MH

Detail Information

Input Voltage(V): 110V/240V Warranty(Year): 5-Year
Working Lifetime(Hour): 3 Year Working Tempreture: -25-50
Application:: ROAD, Highway Material:: Die-casting Aluminum
Solar Panel:: Polycrystalline Silicon Charging Time:: 4-6 Hours
IP Grade:: IP65 Wateproof
High Light:

IP65 High Pressure Sodium Lamp

,

DC Input High Pressure Sodium Lamp

,

IP65 Hps Street Light

Product Description

Quick Detail:

China supplier manufacturing high pressure sodium lamp Street Light , DC input metal halide hps street light



Description

Technical parameters
Lamp body Material Die-casting Aluminum
The light body surface treatment Electrostatic pensu
glass Toughened glass
Lamp holder E40
The efficiency of lamps 80%
Seal material High temperature resistant silicone
Reflective equipment quality High purity aluminum
Reflector processing Anodic oxidation treatment
IP Rating IP65
The anti-corrosion class WF2
Insulation class of lamps I
The net weight of lamps 8.7Kg
Packing size 1080×395×295mm
The introduction of the cable Φ8-12mm
Pick arm diameter of the installation Φ60mm
The light source
The light source power 150W 250W 400W
The light source type High pressure sodium lamp
The light source model NAV
Color rendering ≤25
Color Temperature 2000K
lighting effect ≥100 ≥112 ≥120
The average life span 20000h 32000h
Electrical appliances
Electrical configuration ballast+trigger+Compensation capacitor
Ballast model/specifications NG150ZT NG250ZT NG400ZT
Ballast enameled wire material Copper wire
Ballast life 5years
The trigger model CD-7H
Capacitance specifications PFC20S PFC32S PFC50S
fuse /
Input Voltage/Frequence Range 220V/50Hz
Power Factor ≥0.9
Adjustable light Angle Do not adjust
Lamps and lanterns for way After the qualification



Led street light retrofit sodium lamp



IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 0



IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 1



FEATURES

1) Streamline configuration, graceful appearance combine with the city street environment well;
2) Excellent self-cleaning function;
3) Die-cast aluminium alloy housing guarantees its high soundness;
4) Horizontal or vertical installation are avialable;
5) Original America-imported high power BRIDGELUX LEDs with excellent luminous efficiency.
6) Superior tempered glass diffuser has a good light transmittance and invariant color;
7) Long life power driver ensures above 50000 hours use-life and has short,open-circuit and over-heat protection.
8) Our products had adopted ISO9001:2000 Quality System Authorities and passed CQC,CE,etc.
9) Green and Environmental Protection: No lead, No Mercury, No any environmental pollution.
10) The samples is available, you can order sample to test the quality first.



HPS high press sodium lamp application in City



IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 2

IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 3



Our Service



1. We can offer you the most reasonable and competitive price to start our cooperation.

2. We can ensure you the good quality and on time shipments with our professional QC team control.

3. We can offer you the most considerate service before sales in the sales and after sales: such like pick up,

hotel booking, happy dinner meeting for enough mutual understanding and friendship building; follow orders

to control quality from every step in the production and after production.

4. We can offer you good communication against our time to suit your needs for prompt reaction.

IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 4



IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 5

IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 6

IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 7

Shipping:

1. Specific packaging can be made to order.

You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the

shipping cost after receipt of your order.And also can send by sea or air, kindly send me the port of yours.

The standard procedure for making wooden case is as follows:



IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 8

Inspection of Customer from electricity company in Congo.

IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 9

International Certificate

ASTM,RETIE,Nch203,Costa Rica ASTM,EPC,TCL,ect.



After-Sale Service

Technical Support

Technical support on pre-sales stage. DINGLI has own survey and engineering company with more

than 100 engineers. We have special pre-sales engineer to work with customer at early stage of the project.



IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 10



Site assistance

Site assistance in Latin American market, so far we have sales and service center in Spain, Chile, Bolivia, Peru,

Ecuador, Senegal, which will make a fast response for customer.

Warehouse and Emergency Supply

Warehouse and emergency supply for spare parts, damage parts and missing parts: DINGLI has built production

line in Quito and warehouse for transmission line and distribution network in Ecuador, Bolivia and Senegal with

common use spare parts.

IP65 High Pressure Sodium Lamp Street Light DC Input Metal Halide Hps Street Light 11

Design and Consultant

Supported by both domestic engineering company and Quito tower design center, could provide technical consultant

and design service within our scope of work. For Quito tower design center, most of the engineers are local staffs.

The Design is based on ASTM protocols meantime with GB material standard, which will reduce the weight, and

avoid the replacement on the profiles to save the working time.
