60m 3 Leg Steel Tubular Tower Self Supporting Microwave Transmission Tower

Product Description

60m 3 Leg Steel Tubular Tower Self Supporting Microwave Transmission Tower



Quick Detail:

60m 3 leg self-supporting steel tubular microwave tower

The steel tubular tower structure has relative technical and economic advantages, and is suitable

for transmission towers that bear large loads.



Specifications:

60m 3 leg self-supporting steel tubular microwave tower



Height	0-200 meters
Wind speed	0-320 km/hr (3s gust)
Foundation type	Independent foundation/Raft foundation/Pile foundation
Geological condition	Soft ground/ Mountain ground/ Other
Shape	Triangular / Square
Connection type	Bolts/Nut
Design code	ANSI/TIA-EIA-222-G
Material grade	Q235/345
Deflection	<1/1000 or as client's requirement
Design load	As per client's requirement
Design life	30/50/100 years
Quality system	ISO 9001:2008



Steel tubular tower is a traditional superior product of our factory. Especially the self developed

multi-station flange processing system has significantly improved the precision of geometric tolerance

for each work piece. Thanks to such a process, the 190m high Huangpu large crossing steel tube

tower was appraised as a national quality project. Our factory is supplied with advanced equipment

such as 2400-ton bending machines, line cutting machines, stitch welding machines, and CNC plasma

cutting machines. With these equipment, it is capable to produce equal-diameter tubes and cone-shaped

tubes in polygon and round shape. The CNC stitch welding machine can realize one-time moulding of

stitch welding for steel tube and the welding line can achieve double-size moulding through single welding.

Our factory has been highly affirmed for its production capacity and product quality.



Steel tubular tower members withstand low wind pressure, large cross-section bending rigidity, simple structure,

and clear force transmission, which can give full play to the material's bearing performance. On the one hand,

it can reduce the weight of the tower and reduce the foundation force; on the other hand, it can help to increase

extremes. Ability to resist natural disasters under conditions. When the strength and stability calculation

requirements are met, the use of a steel pipe tower with a relatively small wind pressure body shape

coefficient can significantly reduce the wind load on the tower body.





Voltage: Power transmission equipment/electric transmission line Angle Iron tower  steel tubular tower

Voltage grade:35KV/66KV/110KV/220KV/330KV/500KV/750KV/800KV/1000KV



Production Process

Here is fabrication process for our transmission tower; however, both parties must discuss all drawings and

confirm all shop drawings, technical specification, and which standard to conform. Before mass production,

we must received all signed approved shop drawings and technical documents from our client.





















































Our Fabrication shall be in strict accordance with detail Drawings prepared by the Contractor and

approved by the Engineer. Fabrication shall begin after the approval of the shop assembly and tests.















































Competitive Advantage:



Why Us

1. Experienced staffs replying your inquiry in 24 working hours in fluent English.

2. Customized design is available. OEM&UBM are welcomed.

3. Perfect after sales service. Exclusive and unique solution can be provided to our customer by our

well-trained and professional engineers and staff.

4. Professional factory direct :Best price and timely delivery can be assured.

5. Very convenient transportation.

6. As an honest seller, we always use superior raw material, advanced machines, skilled technicians

to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit

our company anytime.



In the whole pole and tower manufacturing industry, experienced engineers and designers make the

Company be available of designing accurately and timely and ensuring quality, safety and easy construction.

On the basis of an excellent design team, the Company further configures software of PLS-Tower,

AutoCAD, BOCAD and other CAD and updates the software in real time to ensure the software is the latest.

Supported by both domestic engineering company and Quito tower design center, could provide technical

consultant and design service within our scope of work. For Quito tower design center, most of the

engineers are local staffs. The Design is based on ASTM protocols meantime with GB material standard,

which will reduce the weight, and avoid the replacement on the profiles to save the working time.

Project management—Your Dingli Utility project manager oversees all the details necessary to ensure

your project delivers as specified. What’s more, he/she communicates with you every step of the way.
