36kv 66kv 132kv Glass Suspension Type Insulator String For Pole Lines

Product Description

36kv 66kv 132kv suspension glass insulator string for pole lines



Total Solution the field below:
Small hydro power station·Overhead transmission line·Substation,including mobile substation

and modular substation·Distribution network·Electricity Maintenance·Electricity investment·

Telecom tower and accessories

Quick Detail:

36kv 66kv 132kv suspension glass insulator string for pole lines has become popular in transmission line and

distribution line system. To attach the conductors to angle,strain,section or dead-end supoorts,multiple insulator

sets are used,whose insulator strings should be directly connected to the crossarm by means of hinges or shackles.















































































































36kv 66kv 132kv suspension glass insulator string for pole lines



Specification:

IEC designation	U70BL	U70BLP
Diameter D( mm )	225	255
Socket coupling( mm )	146	146
Creepage distance L( mm )	295	320
Socket coupling( mm )	16	16
Mechanical failing load( KN )	70	70
Wet power frequency withstand voltage( kV )	40	40
Dry lightning impulse withstand voltage( kV )	100	100
Impulse puncture voltage( P.U )	2.8	2.8
Power frequency puncture voltage( kV )	110	110
Radio influence voltage( µV )	50	50
Corona visual test( kV )	18/22	18/22
Power frequency electric arc voltage	0.12s/20ka	0.12s/20ka
Net weight per unit( kg )	4.7	5.8
