Electricity Substation Distribution Transformer Hot Dip Galvanization Surface

Product Description

Electricity Substation Distribution Transformer Hot Dip Galvanization Surface



Quick Detail:

Electricity Substation Distribution Transformer Substation Distribution Transformer Substation



Steel structure: light weight, high operational reliability ,earth-quake resistance, impact resistance, high

degree of industrialization, easy to install.



Specifications:



Product Name	Electricity Substation Distribution Transformer Substation Distribution Transformer Substation
Applications	Electrical Power Transformer Substation
Shape	Conical, Round, Polygonal (Octagonal, Dodecagonal, Hexadecagonal, etc)
Surface Treatment	Hot dip galvanization in accordance with Chinese standard GB/T 13912-2002 or American standard ASTM A123 or AS/NZS 4680:2006 Can be powder coated or painted according to clients' request
Material	Hot Roll Steel Q235, Q345, Q420, Q460, ASTM A527 A36, GR50, GR65, ST-37, ST-44, ST-52, S355JR, S355J2G3, SS41, SS50, SS55 and others equivalent steel material
Wall Thickness	2.3~18mm
Once Forming	16m Once forming without joint
Welding	Welding complies with AWS D1.1 standard. CO2 welding or submerged arc auto methods No fissure, scar, overlap, layer or other defects Internal and external welding makes the pole more beautiful in shape If customers need any other requirements of welding, we also can make adjustment ad your request
Joint	Joint with insert mode, flange mode.
Base plate	Base plate is square/round/Polygon with slotted holes for anchor bolt and dimension as per client's requirement.
Life Period	More than 25 years, it is according to installing environment





Hot dip galvanizing	Standard	Steel thickness/mm	Mean coating thickness/μm	Metallic Element	Content
Pole shafts,cross arms&bolted on accessories	ASTM A123/ A123M-15 AS/ NZS 4680	>6	85	Mn	0.25%-0.40%
		<3-6	70
		1.5-3	55	Cu	<0.15%
		<1.5	55
Bolts,nuts&washers	GB/T 5267.3-2008	_____	≥ 54	P	<0.025%
	(ISO 10684-2004)
Foundation bolts	ASTM A153/ A153M-09	_____	≥ 54	S	<0.03%





Steel grades
Factory Building Substation structure: Chinese steel Q345B, which same to ASTM A572 GR50
Other webs, bracing and not stress plate and angle steel: Chinese Q2230B, which same to ASTM A36
Plates: Chinese steel Q345B, which same to ASTM A572 GR50
Bolts: Chinese grade 6.8 and 8.8, which similar to ASTM A394
A) Dimension and tolerance for angle are according to GB/T1591-1994, similar to EN 10056-1/2
B) Hot dip galvanization in accordance with GB/T 13912-2002, which similar to ASTM A 123
C) The welding will be performance in accordance with AWS D1.1 or CWB standard



Competitive Advantage:



Why Us



1. Experienced staffs replying your inquiry in 24 working hours in fluent English.



2. Customized design is available. OEM&UBM are welcomed.



3. Perfect after sales service. Exclusive and unique solution can be provided to our customer by our well-trained

and professional engineers and staff.



4.Professional factory direct :Best price and timely delivery can be assured.



5. Very convenient transportation.



6. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to

ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our

company anytime.



In the whole pole and tower manufacturing industry, experienced engineers and designers make the

Company be available of designing accurately and timely and ensuring quality, safety and easy construction.

On the basis of an excellent design team, the Company further configures software of PLS-Tower, AutoCAD,

BOCAD and other CAD and updates the software in real time to ensure the software is the latest.



Supported by both domestic engineering company and Quito tower design center, could provide technical

consultant and design service within our scope of work. For Quito tower design center, most of the engineers

are local staffs. The Design is based on ASTM protocols meantime with GB material standard, which will

reduce the weight, and avoid the replacement on the profiles to save the working time.



Project management—Your Dingli Utility project manager oversees all the details necessary to ensure your

project delivers as specified. What’s more, he/she communicates with you every step of the way.



 International Certificate

ASTM,RETIE,Nch203,Costa Rica ASTM,EPC,TCL,ect.

After-Sale Service

Technical Support

Technical support on pre-sales stage. DINGLI has own survey and engineering company with more than

100 engineers. We have special pre-sales engineer to work with customer at early stage of the project.

Site assistance

Site assistance in Latin American market, so far we have sales and service center in Spain, Chile,

Bolivia, Peru, Ecuador, Senegal, which will make a fast response for customer.

Warehouse and Emergency Supply

Warehouse and emergency supply for spare parts, damage parts and missing parts: DINGLI has built

production line in Quito and warehouse for transmission line and distribution network in Ecuador, Bolivia

and Senegal with common use spare parts.

Design and Consultant

Supported by both domestic engineering company and Quito tower design center, could provide technical

consultant and design service within our scope of work. For Quito tower design center, most of the engineers

are local staffs. The Design is based on ASTM protocols meantime with GB material standard, which will reduce

the weight, and avoid the replacement on the profiles to save the working time.



Delivery Site of Client

 Package

Set-wisely packing or member-wisely packing as per client's requirements.

Tower members: One steel tower is separated into several bundles.

Bolts: Packing material is robust nylon bag or steel drum.



Global-network map

International Fully Automatic Pollution-free Galvanizing Line

All the production line of galvanization is sealed off, it is operated by 7 workers with a yearly capacity of

160,000 tons.

In the new production line, we invest whole package of lifting equipment, all the loading works will be completed

in our factory, in this case, it will be avoided two times loading during transportation, we are doing our best to

protecting our products as always.

The new production line has improved on the part number tracking system, with this system we are doing better

to avoid the missing parts problem

Customer Visit

Clients of Bolivia visited Dingli for factory inspection, we talked about the key issues faced right now, and found

ways to solve it together. They set a high value on this cooperation.
