11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof

Minimum Order Quantity : Negotiation Price : Negotiation
Packaging Details : sea worthy : professional packing, plastic bag, carton, pallets if clients needed. Delivery Time : Depends on the quality of client
Payment Terms : 30% advanced payment , 70% balance payment before shipment. Supply Ability : 50000 Piece/Pieces per Month
Place of Origin: China Brand Name: DINGLI
Certification: CCC, CE, CQC, RoHS Model Number: VARIOUS

Detail Information

Model Number: GM-SOL-9A, GM-SOL-9A LED Watt: 60w
Solar Panel: Polycrystalline Silicon/Monocrystalline Silicon Solar Panel Power: 120w
Battery Capacity: 120Ah/12v Battery Type: Gel/Lead-acid/Lithium Battery
Lighting Time: 12 Hours Control Mode: Light Control + Time Control
Pole Height: 9m Protective Function: Overcharging,discharging,voltage Surge,reverse Polarit
Item Type: Street Lights Warranty(Year): 3
Lamp Power(W): 60 Lamp Body Material: Aluminum Alloy
Lamp Luminous Efficiency(lm/w): 110 Color Temperature(CCT): Cool White, Warm White, Pure White
High Light:

high pressure sodium lights

,

cobra led street light

Product Description

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof

Quick Detail:

Hot sale 70w 150w 250w ip65 waterproof with photocell high pressure sodium lamp aluminium casting housing for street

Description

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 0

Product name Hot sell 60W LED solar street lights lighting effect equal to 250W high pressure sodium lamp
Model No. GM-SOL-9A
Performance Lighting time per day 12hours (4h full power mode+8h half dimming mode)
Autonomy days 3 days
Solar Modules Power (Wp) 120Wp (17.2V)
Type Poly crystalline silicon
Dimension 1170*670*35mm
Weight 9.2kg
Light Fixture Material Aluminum die casting & Toughened glass
Operating Temperature -40℃~70℃
Protection Level IP65
LED Light Source Power 60W
LED Chip Bridgelux LED chips with high brightness, or customized
Color Temperature 3500-5500K(warm white/pure white/cold white)
Luminous flux 11000lm
Operating temperature 20℃~ 65℃
Lighting Pole Height 9m
Material Q235
Surface Treatment Hot-dip galvanizing, Static spray for led solar street light
Battery Capacity 120AH (12V)
Type Gel/Lead-acid Battery
Dimension 410*175*235mm
Weight 37kg
Controller Rated voltage and current 24V/10A
Weight 0.165Kg
Control mode Light control + time control
IP level IP67
Protective Function overcharging, discharging, voltage surge, reverse polarity, etc.
Accessories Cable 2.5mm2 19m
Battery Box 120AH waterproof ABS battery box
Foundation Kit Dismountable foundation kit, saving in shipping



Item Pole Height LED watt Solar panel watt Battery capacity Controller
GM-SOL-3 3 10 30 30 12V PWM
GM-SOL-4 4 15 50 50 12V PWM
GM-SOL-5 5 20 60 70 12V PWM
GM-SOL-6A 6 30 60 60 12V PWM
GM-SOL-6B 6 35 90 90 12V PWM
GM-SOL-7A 7 40 80 80 12V PWM
GM-SOL-7B 7 45 120 120 12V PWM
GM-SOL-8A 8 50 100 100 12V PWM
GM-SOL-8B 8 55 150 150 12V PWM
GM-SOL-9A 9 60 120 120 12V PWM
GM-SOL-9B 9 65 180 180 12V PWM
GM-SOL-10A 10 70 150 150 24V MPPT
GM-SOL-10B 10 75 200 200 24V MPPT
GM-SOL-11A 11 80 180 180 24V MPPT
GM-SOL-11B 11 85 220 220 24V MPPT
GM-SOL-12A 12 90 250 250 24V MPPT
GM-SOL-12B 12 100 300 300 24V MPPT



11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 1

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 2

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 3

Shipping:

1.Specific packaging can be made to order.

You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the shipping cost after receipt of your order.And also can send by sea or air, kindly send me the port of yours.

The standard procedure for making wooden case is as follows:



11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 4

Inspection of Customer from electricity company in Congo.

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 5



1. About us

HENAN DINGLI was founded in 1963 as a small electric power equipment manufacturer, after more than 50 years’development, DINGLI now is group company dedicated on total solutions for electricity projects covering survey, design, manufacture, complete equipment supply, construction, operations, maintenance, investment and so on. HENAN DINGLI actively devote to power grid construction, participated in all UHV construction projects and made an outstanding contribution to UHV transmission lines of China.

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 6



Since 2000, HENAN DINGLI has been actively developing international business, successively built Ecuador, Cambodia manufacturing Base, Quito tower design center, Spain, Peru, Chile and other overseas service centers. We have got a number of international certificates, such as ISO certificate covering design, equipment and construction, AWS welding certificate, ASTM system certificate, Chile NCH 203 certificate, Colombia RETIE certificate, Costa Rica material quality Certificate, etc. By the end of 2018, the overall proportion of international business is more than 30% of the company's main revenue. We have provided high-quality products and services to more than 100 customers in 33 countries, including the markets of Europe, America, Africa and Southeast Asia. With strong technical support and on-site service capability, HENAN DINGLI has saved a lot of project costs for customers and won their recognition.

2. International Certificate

ASTM,RETIE,Nch203,Costa Rica ASTM,EPC,TCL,ect.

3. After-Sale Service

Technical Support

Technical support on pre-sales stage. DINGLI has own survey and engineering company with more than 100 engineers. We have special pre-sales engineer to work with customer at early stage of the project.



11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 7



Site assistance

Site assistance in Latin American market, so far we have sales and service center in Spain, Chile, Bolivia, Peru, Ecuador, Senegal, which will make a fast response for customer.

Warehouse and Emergency Supply

Warehouse and emergency supply for spare parts, damage parts and missing parts: DINGLI has built production line in Quito and warehouse for transmission line and distribution network in Ecuador, Bolivia and Senegal with common use spare parts.

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 8

Design and Consultant

Supported by both domestic engineering company and Quito tower design center, could provide technical consultant and design service within our scope of work. For Quito tower design center, most of the engineers are local staffs. The Design is based on ASTM protocols meantime with GB material standard, which will reduce the weight, and avoid the replacement on the profiles to save the working time.

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 9

Package

Set-wisely packing or member-wisely packing as per client's requirements.







 Global-network map

China

Henan DINGLI Pole and Tower Co., ltd.

Henan Zhongdingxin Detection Technology Co.,ltd.

Henan Dadi Electricity Engineering Co.,ltd.

Henan DINGLI Power Equipment Co.,ltd

Henan DINGLI Power Construction Co., ltd

Huading Concrete Pole Co., Ltd

Xingjiang Huili Steel Tower Co., Ltd.

Bazhou Dingli Tower Co., Ltd.

Shanghai Sales and Service Center

Beijing Sales and Service Center



Cambodia

Cambodia Phnom Penh Factory



Spain

Madrid (Spain) Sales and Service Center



Dakar, Senegal



Senegal (Dakar) Sales and Service Center

Senegal (Dakar) Spare Part Warehouse



Quito, Ecuador



Quito (Ecuador) Steel Tower Design Center (ASTM Standard)

Quito (Ecuador) Steel Tower Emergency Production Line

Quito (Ecuador) Raw Material and Spare Part Warehouse



Lima, Peru

Lima (Peru) Sales and Service Center



Cochabamba, Bolivia

Cochabamba (Bolivia) Raw Material and Spare Part Warehouse



Santiago, Chile

Santiago (Chile) Sales and Service Center



Jakarta, Indonesia

Jakarta (Indonesia) Sales and Service Center





11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 10





Customer Visit

Clients of Bolivia visited Dingli for factory inspection, we talked about the key issues faced right now, and found ways to solve it together. They set a high value on this cooperation.





Customers and Partners of Dingli

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 11

11000lm High Pressure Sodium Lamp 60w Led Solar Street Lights Waterproof 12
