Product Name: 5G Communication Network 30-70m Construction Angle Steel Telecom Tower
Product Application
Communication tower consists of tower body, platform, lightning rod, ladder, antenna support and other steel components, and by hot galvanized anti-corrosion treatment, mainly for microwave, ultrashort wave, wireless network signal transmission and transmission.
Specifications of galvanized telescopic antenna mast:
Single pipe tower antenna monopole communication tower | |
Brand | DINGLI |
Material | Q355/Q345/Q235/Q420 steel |
Surface treatment | Hot dip galvanized/painting |
Height | 1-80m, also can customized as buyer’s requirements |
Wind speed | 30-50m/s, also can customized as buyer’s requirements |
Payload | 500kg, also can customized as buyer’s requirements |
Connection type | Flange |
Service life | More than 30 years |
Application | Park, uptown, playground, street, etc |
Standard | GB |
Certification | ISO9001 |
Delivery time | Within 20 days or depend on the quantity of pole |
OEM | OK |
Welding | Standard | Standard Title |
Pole shafts&multi-sided tubular Cross arms&all accessories |
AWS D1.1/D1.1M:2010 | Structural Welding Code-Steel |
Welding wire | AWS D1.1/D1.1M:2010 | Structural Welding Code-Steel |
Hot dip galvanizing | Standard | Steel thickness/mm | Mean coating thickness/μm | Metallic element | Content |
Pole shafts,cross arms&bolted on accessories | ASTM A123/A123M-15 AS/NZS 4680 | >6 | 85 |
Mn
|
0.25%-0.40%
|
<3-6 | 70 | ||||
1.5-3 | 55 |
Cu
|
<0.15%
|
||
<1.5 | 55 | ||||
Bolts,nuts&washers |
GB/T 5267.3-2008 (ISO 10684-2004) |
_____ | ≥ 54 | P |
<0.025%
|
Foundation bolts | ASTM A153/A153M-09 | _____ | ≥ 54 |
S
|
<0.03% |
Place of Origin: | Henan China (Mainland) |
Brand name: | DINGLI |
Color: | User-defined |
Certificate: | ISO9001:2008 |
Surface Treatment: | Hot Dip Galvanized |
Service life: | 30 years |
Material: | Steel |
Spare Parts: | Parts for connection or installation |
Height: | 6-50m |
Packaging details: | Standard seaworthy package(wooden boxes,cotton ,steel strip and other package)or as buyers' requirement |
Specifications:
The technical parameters meet the following standard:
Design wind speed: 30M/S (varies by regions)
Icing depth: 5mm-7mm: (varies by regions)
Aseismatic intensity: 8°
Preference temperature: -35℃~45℃
Vertical missing: <1/1000
Ground resistance: ≤4Ω
Preservative treatment: the steel member of the tower is treated with hot dip galvanized anti-corrosion technology, which ensures the tower doesn’t get rusted within 35 years.
Main functions of the communication tower: to support signal transmitting antenna.
Material origin: Baosteel/Shougang Group/Handan Steel/Tangshan Iron & Steel, etc.
Hot dip galvanizing | Standard | Steel thickness/mm |
Mean coating thickness/μm |
Metallic element | Content |
Pole shafts,cross arms&bolted on accessories |
ASTM A123/ A123M-15 AS/ NZS 4680 |
>6 | 85 | Mn | 0.25%-0.40% |
<3-6 | 70 | ||||
1.5-3 | 55 | Cu | <0.15% | ||
<1.5 | 55 | ||||
Bolts,nuts&washers | GB/T 5267.3-2008 | _____ | ≥ 54 | P | <0.025% |
(ISO 10684-2004) | |||||
Foundation bolts |
ASTM A153/ A153M-09 |
_____ | ≥ 54 | S | <0.03% |
