Gas Insulated Substation 10 MVA Mobile Transformer Substation

Minimum Order Quantity : 1 Price : Negotiation
Packaging Details : According to client's request. 7.5mva 33kv semi-trailer transformer substation 11/0.4kv Delivery Time : 50~60 days
Payment Terms : 30% advanced payment , 70% balance payment before shipment. Supply Ability : 10 Set/Sets per Year semi-trailer transformer substation
Place of Origin: China Brand Name: DINGLI
Model Number: Mobile substation

Detail Information

Certification: ISO9001/CE Material: Copper
Type: Dry Type Model Number:: CZBT1
Standard: IEC 60076 Rated Voltage: Rated Voltage
Usage: Electricity Transmission Project Product Name: 7.5mva 33kv Semi-trailer Transformer Substation
Rated Capacity: 7.5mva Retated Current On LV Side: 1250A
Retated Voltage: 6.6 Kv Wind Speed: 40m/s
Ambient Temperature: -40 ~ +60℃
High Light:

10 MVA Mobile Transformer Substation

,

Gas Insulated Mobile Transformer Substation

,

10 MVA gas insulated substation

Product Description

Trailer for gas insulated substation 10 MVA mobile transformer substation power transformer



Gas Insulated Substation 10 MVA Mobile Transformer Substation 0

Total Solution for the field below:
Small hydro power station·Overhead transmission line·Substation,including mobile substation

and modular substation·Distribution network·Electricity Maintenance·Electricity investment·

Telecom tower and accessories

Quick Detail:

Trailer for gas insulated substation 10 MVA mobile transformer substation power transformer



Product Description

The Mobile Substation,supply by us is mainly used as a quick substation to the conventional substation to resume power supply in emergency. It be Used In the high-load season alleviate the shortage of power supply capacity and As a temporary substation put into operation. It can be put into immediate ser vice with just a simple laid out,connecting to the incoming and outgoing cables upon arrival at the site. The mobile substation has the advantages of compact structure,reliable operation,complete functions,highly intelligent,quick site operation,less maintenance,etc, Prefabricated semi-care hanging car mobile substation can be designed according to user requirements, can be configured as twin car or bicycle or car based on user conditions.



Function & features​:

It has all the function of ordinary substation.
(1) It is Include control, protection, lighting protection and step-down and other functions.
(2) It can be assigned to several power users of branches.
It is easy to install and put into operation quickly.

Just connect the cable to put into operation.

It has shock absorption, temporary rod, circuit components soft connection and other shock measures.



Structural composition:

It is divided into HV part, main transformer, LV switchgear room.
High pressure switches use HGIS or open type isolating switch and magnetic pole breaker as the main switch, mounted on a trailer.

LV switchgear room include: Low voltage side switch cabinet, control power supply, DC screen and measuring equipment control protection.

LV inner switchgear features

Use three-layer insulation shell;

Air-conditioned, open on demand;

Shell protection grade up to IP43 substation;

Indoor DC power supply battery of low-voltage switchgear is fully sealed products.



Technical Data:

No Item Unit Parameter
1 Main transformer capacity MVA 5, 7.5, 10, 15, 20, 25, 31.5, 40, 50
2 Rated voltage of the switch on HV side kV 33, 35, 66, 110, 132, 145, 220
3 Rated current on HV side A 630, 1250, 2000
4 Rated short circuit breaking current kA 25, 31.5, 40
5 Rated voltage of the switch on LV side kV 6.6, 11, 13.8, 22, 33, 35
6 Rated current on LV side A 1250, 2000, 2500, 3150
7 Rated short circuit breaking current kA 25, 31.5, 40
8 Rated frequency Hz 50/60
Ambient Environment
10 Ambient temperature -40 ~ +60
11 Solar radiation W/m2 1000
12 Humidity % ≤95
13 Height above sea level m ≤2000
14 Wind Speed m/s 40
15 Earthquake Horizontal acceleration g General area:0.15g Stricken area:0.3g
Vertical acceleration g General area:0.075g Stricken area:0.15g



Product Name Mobile substation
Main transformer capacity 5000kVA~63000kVA
Voltage level 10kV~220kV
Composition configuration Main Transformer Vehicle and Distribution Vehicle, Customized
Inlet Form Overhead or cable access
Outgoing form Cable outlet
Outgoing configuration 35kV and 10kV can reach 8-10 routes





Gas Insulated Substation 10 MVA Mobile Transformer Substation 1Gas Insulated Substation 10 MVA Mobile Transformer Substation 2Gas Insulated Substation 10 MVA Mobile Transformer Substation 3
