33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line

Minimum Order Quantity : Negotiation Price : Negotiation
Packaging Details : Standard National Packing Method Delivery Time : Depends on the quality of client
Payment Terms : 30% advanced payment , 70% balance payment before shipment or negociatable, T/T Supply Ability : 2000 Ton per Month
Place of Origin: china Brand Name: China
Certification: ISO9001,ASTM,RETIE,Nch203,Costa Rica ASTM,EPC,TCL,Q690 Extra High Strength Steel Model Number: DINGLI

Detail Information

Material: ASTM A36,ASTM A572 GR65, GR50, Etc. Available Height: 5-100M
Surface Coating: Hot Dip Galvanization Or Painting Wind Speed: 160 Km/Hour . 30 M /s
Galvanization: Hot Dip Galvanization Power: 10 KV ~550KV
High Light:

400kv Galvanized Steel Tower

,

33kv Galvanized Steel Tower

,

33kv Power Distribution Pole

Product Description

33kv-400kv galvanized steel power distribution pole electrical transmission line steel tower price

Quick Detail:

Product features:

Type
Straight Pole ,Tensile Pole ,Turn Pole
Suit for
Electricity distribution
Shape
Conoid ,Multi-pyramidal , Columniform,polygonal or conical
Material
Usually Q345B/A572,minimum yield strength>=345n/mm2
Q235B/A36,minimum yield strength>=235n/mm2
As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52
Tolerance of dimension
+- 2%
Power
10 KV ~550 KV
Safety Factor
Safety factor for conducting wine : 8
Safety factor for grounding wine : 8
Design Load in Kg
300~ 1000 Kg applied to 50cm from the top pole
Marks
Nane plate through rivert or glue ,engrave ,emboss as per customer requirement
Surface treatment
Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles
Insert mode,innerflange mode,face to face joint mode .
Design of pole
Against earthquake of 8 grade
Wind Speed
160 Km/Hour . 30 m /s
Minimum yield strength
355 mpa
Minimum ultimate tensile strength
490 mpa
Max ultimate tensile strength
620 mpa
Standard
ISO 9001
Length of per section
Within 14m once forming without slip joint
Welding
We have past flaw testing. Internal and external double welding makes the welding beautiful in shape
Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness
1 mm to 30 mm



Production Process And Quality Control

33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 0

Main Features
1. We can supply the product base on client required drawing ,but also can supply the design for any kinds
of lamp poles ,electric poles ,street lighting poles, high mast poles ,garden light poles , outdoor lighting
,outdoor lighting poles ,flag poles ,traffic light poles ,lighting ,road lighting pole.
2. Material :hot rolled coil from Q235 to Q460 ,ASTM573 GR65, GR50 ,SS400, SS490,ST52-3 equivalent
standard materials
3. deal: Hot dip galvanized Following ASTM A 123 or any other standard by client required.
4. Packing: Plastic bulble , Mat &Straw Bale or following client required
5. Length : within 16meters once forming( single section)
6. Thickness: from 1mm to 25mm
7. Shape: polygonal(6-side,8side,12-side,16side) round tapered.
8. 110KV to 220kv
9. Easy install and maintenance.

Tower Detials:
33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 1


Competitive Advantage:
Why Us

1. Experienced staffs replying your inquiry in 24 working hours in fluent English.
2. Customized design is available. OEM&UBM are welcomed.
3. Perfect after sales service. Exclusive and unique solution can be provided to our customer by our well-trained
and professional engineers and staff.
4. Professional factory direct :Best price and timely delivery can be assured.
5. Very convenient transportation.
6. As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure
our products to be finished in high quality and stable feature. Welcome to contact us or visit our company anytime.
7. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers
and staff.
8. Special discount and protection of sales are provided to our distributor.
9. Professional factory : We are manufacturer, specializing in producing all kinds of steel poles for more than 20
years, competitive with good quantity.
Service
Experienced senior engineers and technical staff keeping on learning can help perform design accurately and
timely and ensure quality, reliability and innovation of products. With the help of the latest advanced design
software of PLS-Pole and AutoCAD, experienced engineers of the Company can design schemes meeting
complex landform and environment, so as to meet various needs of customers.
In the whole pole and tower manufacturing industry, experienced engineers and designers make the Company
be available of designing accurately and timely and ensuring quality, safety and easy construction. On the basis
of an excellent design team, the Company further configures software of PLS-Tower, AutoCAD, BOCAD and other
CAD and updates the software in real time to ensure the software is the latest.
Supported by both domestic engineering company and Quito tower design center, could provide technical consultant
and design service within our scope of work. For Quito tower design center, most of the engineers are local staffs.
The Design is based on ASTM protocols meantime with GB material standard, which will reduce the weight, and
avoid the replacement on the profiles to save the working time.
Project management—Your Dingli Utility project manager oversees all the details necessary to ensure your
project delivers as specified. What’s more, he/she communicates with you every step of the way.


33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 2
International Certificate
ASTM,RETIE,Nch203,Costa Rica ASTM,EPC,TCL,ect.
After-Sale Service
Technical Support
Technical support on pre-sales stage.



DINGLI has own survey and engineering company with more than
100 engineers. We have special pre-sales engineer to work with customer at early stage of the project.
33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 3
Site assistance
Site assistance in Latin American market, so far we have sales and service center in Spain, Chile, Bolivia, Peru,
Ecuador, Senegal, which will make a fast response for customer.
33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 4
Warehouse and Emergency Supply
Warehouse and emergency supply for spare parts, damage parts and missing parts: DINGLI has built production
line in Quito and warehouse for transmission line and distribution network in Ecuador, Bolivia and Senegal with
common use spare parts.
33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 5
Design and Consultant
Supported by both domestic engineering company and Quito tower design center, could provide technical
consultant and design service within our scope of work. For Quito tower design center, most of the engineers
are local staffs. The Design is based on ASTM protocols meantime with GB material standard, which will reduce
the weight, and avoid the replacement on the profiles to save the working time.
Package
Our poles as normal cover by Mat or straw bale at the top and bottom and wood between the poles to avoid the
damage on the galvanization of the pole ,anyway also can following by client required , The loading capacity of
40HC or OT an be calculated calculation base on the client actually specification and data.

33kv-400kv Galvanized Steel Tower Power Distribution Pole Electrical Transmission Line 6
