Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv

Minimum Order Quantity : Negotiation Price : Negotiation
Packaging Details : Standard National Packing Method Delivery Time : Depends on the quality of client
Payment Terms : 30% advanced payment , 70% balance payment before shipment. Supply Ability : 12000 Piece/Pieces per Month
Place of Origin: China Brand Name: DINGLI
Model Number: FZSW-110/8

Detail Information

Certification: ISO9001:2015 Material: Composite Polymer, Silicone Rubber
Type: Insulator Model Number:: FZSW-110/8
End Fitting Type: Post Type Surface: Vulcanization
Application: High Voltage Rated Voltage: 110KV
Tensile Strength: 8KN Inner Material: Stainless Steel,external Galvanizing
High Light:

Higher Tensile Electric Post Insulators

,

Electric Post Insulators 145kv

,

Electric Post Insulators 150kv

Product Description

Higher Tensile Electrical Substation 145kv 150kv Composite Electric Pole Post Insulator



Quick Detail:

Polymer post Insulator Product Parameter
Type Rated voltage(KV) Specifified bending load Section length(mm) Min Arcdistance(mm) Leakage distance (mm) Lightning impulse withstand BIL(KV) Power frequency withstand(wet) (KV)
FZSW-11/4 11 4 265 155 430 75 42
FZSW-24/8 24 8 395 280 760 150 65
FZSW-33/6 33 6 430 320 870 185 80
FZSW-36/6 36 6 445 335 920 185 95
FZSW-66/8 66 8 850 585 2570 400 130
FZSW-66/10 66 10 860 720 2539 350 160
FZSW-72.5/12.5 72.5 12.5 760 590 1950 400 185
FZSW110/10 110 10 1050 885 3330 550 185
FZSW-126/8 126 8 1220 1055 3500 550 185
FZSW-132/10 132 10 1500 1300 3600 765 430
FZSW220/10 220 10 2440 2200 7060 1000 395

Product Display

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 0

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 1

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 2

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 3

Product Advantage

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 4

Product Application

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 5



Packaging

1. Specific packaging can be made to order.

You can specify other shipping methods such as Airmail, FEDEX or DHL. We shall let you know about the

shipping cost after receipt of your order.And also can send by sea or air, kindly send me the port of yours.

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 6















































1. About us

HENAN DINGLI was founded in 1963 as a small electric power equipment manufacturer, after more

than 50 years’development, DINGLI now is group company dedicated on total solutions for electricity

projects covering survey, design, manufacture, complete equipment supply, construction, operations,

maintenance, investment and so on. HENAN DINGLI actively devote to power grid construction, participated

in all UHV construction projects and made an outstanding contribution to UHV transmission lines of China.

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 7















































Since 2000, HENAN DINGLI has been actively developing international business, successively built Ecuador,

Cambodia manufacturing Base, Quito tower design center, Spain, Peru, Chile and other overseas service centers.

We have got a number of international certificates, such as ISO certificate covering design, equipment and construction,

AWS welding certificate, ASTM system certificate, Chile NCH 203 certificate, Colombia RETIE certificate, Costa Rica

material quality Certificate, etc. By the end of 2018, the overall proportion of international business is more than 30%

of the company's main revenue. We have provided high-quality products and services to more than 100 customers in

33 countries, including the markets of Europe, America, Africa and Southeast Asia. With strong technical support and

on-site service capability, HENAN DINGLI has saved a lot of project costs for customers and won their recognition.

2. International Certificate

ASTM,RETIE,Nch203,Costa Rica ASTM,EPC,TCL,ect.

3. After-Sale Service

Technical Support

Technical support on pre-sales stage. DINGLI has own survey and engineering company with more than 100 engineers.

We have special pre-sales engineer to work with customer at early stage of the project.

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 8

















































Site assistance

Site assistance in Latin American market, so far we have sales and service center in Spain, Chile, Bolivia, Peru, Ecuador, Senegal, which will make a fast response for customer.

Warehouse and Emergency Supply

Warehouse and emergency supply for spare parts, damage parts and missing parts: DINGLI has built production line in Quito and warehouse for transmission line and distribution network in Ecuador, Bolivia and Senegal with common use spare parts.

Design and Consultant

Supported by both domestic engineering company and Quito tower design center, could provide technical consultant and design service within our scope of work. For Quito tower design center, most of the engineers are local staffs. The Design is based on ASTM protocols meantime with GB material standard, which will reduce the weight, and avoid the replacement on the profiles to save the working time.

Package

Set-wisely packing or member-wisely packing as per client's requirements.



Global-network map

China

Henan DINGLI Pole and Tower Co., ltd.

Henan Zhongdingxin Detection Technology Co.,ltd.

Henan Dadi Electricity Engineering Co.,ltd.

Henan DINGLI Power Equipment Co.,ltd

Henan DINGLI Power Construction Co., ltd

Huading Concrete Pole Co., Ltd

Xingjiang Huili Steel Tower Co., Ltd.

Bazhou Dingli Tower Co., Ltd.

Shanghai Sales and Service Center

Beijing Sales and Service Center

Cambodia

Cambodia Phnom Penh Factory

Spain

Madrid (Spain) Sales and Service Center

Dakar, Senegal

Senegal (Dakar) Sales and Service Center

Senegal (Dakar) Spare Part Warehouse

Quito, Ecuador

Quito (Ecuador) Steel Tower Design Center (ASTM Standard)

Quito (Ecuador) Steel Tower Emergency Production Line

Quito (Ecuador) Raw Material and Spare Part Warehouse

Lima, Peru

Lima (Peru) Sales and Service Center

Cochabamba, Bolivia

Cochabamba (Bolivia) Raw Material and Spare Part Warehouse

Santiago, Chile

Santiago (Chile) Sales and Service Center

Jakarta, Indonesia

Jakarta (Indonesia) Sales and Service Center

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 9









































Customer Visit

Clients of Bolivia visited Dingli for factory inspection, we talked about the key issues faced right now,

and found ways to solve it together. They set a high value on this cooperation.



Customers and Partners of Dingli

Higher Tensile Composite Electric Post Insulators Electrical Substation 145kv 150kv 10
